MINI WHEEL LOADER SEM618D

SPECIFICATION

MINI WHEEL LOADER SEM618D	SPECIFICATION
Rated load	1800 kg
Operating weight with standard bucket	5940 kg
Bucket capacity	0.9-1.0 m3
Wheel base	2200 mm
Overall dimension	5901 * 2000 * 2822 mm
Max. Tractive force	55 kN
Max. Breakout force	63 kN
Max. Dumping height	2691 mm
Gearbox	ZL15
Gear shift	Forward 2 and reverse 2
Torque converter	Single stage, 3 elements
Max. Travel Speed	24 km/h
Axles	ZL16
Engine Model	YTO YT4B4-22
Rated Power	60 kW @ 2200 r/min
Displacement	4.76 L
Boom raise time	4.35 s
Hydraulic cycle time	7.8 s
System Pressure Setting	17 MPa
Service brake	Dry & Caliper, Air to oil control
Parking brake	Disk & caliper
Tire Size	16/70-20

ADVANTAGE

• The engine of Mini Loader SEM618D is China famous YTO brand with high efficiency thermal energy control technology and Special lower fuel/oil consumption technology.
• Mini Loader SEM618D can adapt all kinds of climate conditions with Large radiator for over 50℃ high temperature conditions and engine preheat for under -35℃ high cold conditions.
• Efficient hydraulic system of Mini Loader SEM618D is equipped with higher reliable pump, valve and hose and full load-sensing steering system brings lower fuel consumption and good operation feeling.
• Mini Loader SEM618D's Luxury 360-view lower noise comfortable cabin with air conditioner and Premium fiber 4 direction and suspension adjustable seat.
• Mini Loader SEM618D is widely used in municipal, livestock production, farms and also in industrial, recycled material processing in countryside, cement making etc .

• Chinese brands ranking in the world top 50 construction machinery manufacturers
