SMALL WHEEL LOADER SEM632D

SPECIFICATION

SMALL WHEEL LOADER SEM632D	SPECIFICATION
Rated load	3000 kg
Operating weight with standard bucket	9700 kg
Bucket capacity	1.53-2.50 m3
Wheel base	2630 mm
Overall dimension	7162 * 2354 * 3051 mm
Max. Tractive force	97 kN
Max. Breakout force	113 kN
Max. Dumping height	3010 mm
Gearbox	SEM TR100
Gear shift	Forward 4 and reverse 2
Torque converter	Single stage, 3 elements
Max. Travel Speed	39 km/h
Axles	Meritor
Engine Model	WEICHAI DEUTZ WP6G125E22
Rated Power	92 kW @ 2200 r/min
Displacement	6.7 L
Boom raise time	4.65 s
Hydraulic cycle time	8.34 s
System Pressure Setting	18 MPa
Service brake	Dry & Caliper, Air to oil control
Parking brake	Drum / shoe
Tire Size	17.5-25

ADVANTAGE

• The engine of Small wheel Loader SEM632D is WEICHAI DEUTZ WP6G125E22 with 93% desert air cleaner to reduce earlier wearing 90% and new designed shock absorber.
• Small wheel Loader SEM632D can adapt all kinds of climate conditions with Large radiator for over 50℃ high temperature conditions and engine preheat for under -35℃ high cold conditions.
• Efficient hydraulic system of Small wheel Loader SEM632D is with single pump flow shared system for lower fuel consumption and big tractive force and larger breakout force for higher productivity.
• Small wheel Loader SEM632D's cabin with big space, superior visibility, patented MAC mount for less noise and more comfort,sliding side window,fresh air circulated air conditioner, adjustable air flow outlet to deliver better defrost performance and Suspension adjustable seat.
• Small wheel Loader SEM632D is widely used in municipal, livestock production, farms and also in industrial, recycled material processing in countryside, cement making etc .

• Chinese brands ranking in the world top 50 construction machinery manufacturers
